IT8200E Regenerative AC/DC Electronic Load

IT8200E series regenerative AC/DC electronic load can efficiently feed power back to the grid. In a 3U rack, it can input up to 21kVA at most. Through master-slave paralleling connection, its power can be easily expanded to more than 1MVA.
Its touch screen and GUI allow the editing of various waveforms. Combined with arbitrary waveform editing functions and full protection, IT8200E is a good choice for R&D, testing and system integration.
In AC mode, you can turn on the 'Rectified' function to make the IT8200E electronic load work in the first and third quadrant, with the voltage and current maintaining the same direction. It also provides a variety of working modes, such as CE mode, which can simulate 14 circuit topologies. IT8200E series can be used for a wide range of applications, including V2G, EVSE, Inverter, PCS, UPS, etc.

Find a product
Model
Voltage
Current
Power
Resolution
Accuracy
Interface
Size
IT82168E-350-840
350 V
840A
168kVA
0.01V/0.1A
<0.1%+0.1%FS /<0.1%+0.2%FS
USB/CAN/LAN/digital I/O port, optional GPIB/analog & RS232
37U
inquiry
IT82147E-350-735
350 V
735A
147kVA
0.01V/0.1A
<0.1%+0.1%FS /<0.1%+0.2%FS
USB/CAN/LAN/digital I/O port, optional GPIB/analog & RS232
27U
inquiry
IT82126E-350-630
350 V
630 A
126 kVA
0.01V/0.1A
<0.1%+0.1%FS /<0.1%+0.2%FS
USB/CAN/LAN/digital I/O port, optional GPIB/analog & RS232
27U
inquiry
IT82105E-350-525
350 V
525 A
105 kVA
0.01V/0.1A
<0.1%+0.1%FS /<0.1%+0.2%FS
USB/CAN/LAN/digital I/O port, optional GPIB/analog & RS232
27U
inquiry
IT8284E-350-420
350 V
420 A
84 kVA
0.01V/0.1A
<0.1%+0.1%FS /<0.1%+0.2%FS
USB/CAN/LAN/digital I/O port, optional GPIB/analog & RS232
27U
inquiry
IT8263E-350-315
350 V
315 A
63 kVA
0.01V/0.1A
<0.1%+0.1%FS /<0.1%+0.2%FS
USB/CAN/LAN/digital I/O port, optional GPIB/analog & RS232
15U
inquiry
IT8242E-350-210
350 V
210 A
42 kVA
0.01V/0.1A
<0.1%+0.1%FS /<0.1%+0.2%FS
USB/CAN/LAN/digital I/O port, optional GPIB/analog & RS232
6U
inquiry
IT8221E-350-105
350 V
105 A
21 kVA
0.01V/0.1A
<0.1%+0.1%FS /<0.1%+0.2%FS
USB/CAN/LAN/digital I/O port, optional GPIB/analog & RS232
3U
inquiry
IT82231E-350-1155
350 V
1155A
231kVA
0.01V/0.1A
<0.1%+0.1%FS /<0.1%+0.2%FS
USB/CAN/LAN/digital I/O port, optional GPIB/analog & RS232
37U
inquiry
IT82210E-350-1050
350 V
1050A
210kVA
0.01V/0.1A
<0.1%+0.1%FS /<0.1%+0.2%FS
USB/CAN/LAN/digital I/O port, optional GPIB/analog & RS232
37U
inquiry
IT82189E-350-945
350 V
945A
189kVA
0.01V/0.1A
<0.1%+0.1%FS /<0.1%+0.2%FS
USB/CAN/LAN/digital I/O port, optional GPIB/analog & RS232
37U
inquiry
Show all
* The above specifications are subject to change without prior notice.
Product Features
Adopt advanced SiC technology
High power density, 21kVA in 3U unit
Master/Slave parallel, power up to 1MVA+
High efficient energy regeneration
Comprehensive working modes selectable: single-phase, three-phase, reverse phase(split phase). Rated voltage can be extended to 200% under reverse phase(split phase)
Frequency: 16-500Hz
Support NORMAL/LIST/SWEEP/Surge&Sag modes
Built-in various waveforms
Touch screen, simple UI for easy operation
Built-in USB/CAN/LAN/Digital IO interface, optional GPIB/Analog&RS232
Support CANopen*3、Modbus、LXI、SCPI communication
AC mode supports CC/CP/CR/CS/CC+CR/CE multiple working modes, CE mode can simulate 14 circuit topologies such as single-phase rectifier RLC and parallel RLC
AC mode supports both rectification and non-rectification modes
DC mode supports 9 working modes such as CC/CR/CP/CV
Adjustable crest factor: 1.414 ~ 5.0
Supports phase shift, ranging from -90 º to 90.0 º *1
The unit power factor1 function allows the current waveform to vary with the voltage waveform and the power factor is as close to 1 as possible
In three-phase AC mode, two access modes are supported: Y and Δ

Comprehensive harmonics measurement and analysis, up to 50th.

Built-in IEC61000-3-2/3-12 pre-compliance test standard *2

Support the loading and unloading angle control, the full range of 0-359° can be set

Various protection functions such as Protect auto clear (UV&FE auto Clear), POVP, POCP, UVP, Software watchdog

* 1 After the rectification function is enabled, the setting range of phase shift is

restricted by the peak factor
* 2 Voltage/current harmonic analysis, current harmonic simulation, fundamental
wave ≤ 60Hz
* 3 coming soon

Functions and Advantages




Regenerative AC/DC electronic load

The IT8200E series are new regenerative AC Electronic Load with 88% energy recovery capability. Whether in AC mode or DC mode, the power generated by the DUT can be fed back to the grid,rather than being dissipated as heat, which protects the environment and save the cost of electricity, HVAC and cooling infrastructure.


Oscilloscope function

The IT8200E series has built-in digital oscilloscope functions, which can collect time domain signals of voltage and current, phase relationship, and per form waveform triggering, etc. Its sampling rate is as high as 10us, up to 6 oscilloscope curves can be displayed at the same time, and instantaneous analysis can be completed.
Fur ther more, with its data recording function, you can observe the output for a long time, and store the obtained data to an external storage device for secondary analysis. A wide variety of test requirement can be met even without a data acquisition instrument or an oscilloscope.




Single-phase, three-phase, reverse-phase

The IT8200E series has single-phase, three-phase, and reverse-phase output modes, which can be selected through the menu. Under reverse mode, the single-phase 350V input v oltage can be increased to 700V with the power down t o 2/3 of the original. Under the three-phase mode, you can choose a Y-type or a Δ-type connection. The Y-type connection supports the C-phase loss.



Various operating modes

IT8200E AC electronic load can enable the 'Rectified' function in AC mode, so that the load works in the first and third quadrants to ensure that the voltage and current flow always in the same direction. At this time, full wave, positive half wave, or negative half wave can be freely selected.



CF 1.414-5.0

The crest factor indicates the extreme peaks of the waveform. For applications that require a pure sine wave, it is desirable to have a CF v alue of the load curr ent waveform of 1.414 or as close as possible. However, in pr actical applications, the peak shape of the current waveform of the load may become very sharp and its CF is often higher than 1.414. At this time, the starting point of the sine wave starts to shift from 0 degrees to the positive degree. So you need to correct the waveform. The Crest Factor of the IT8200E can be adjusted fr om 1.414 t o 5.0, and it als o allows to set the phas e shift angle fr om -90 º~90 º, corr ect the resulting amplitude, and keep the RMS unchanged. This enables more accurate simulation of field test conditions to ensure the reliability of the unit under test (UUT).

Options & Accessories
  • IT-E9005(Optional)
    ITECH Warranty up to 5 years
  • AC power cord (accessory)
    AC power cord (accessory)
  • USB
    For USB port communication
  • IT-E30312(20)-YY(Optional)
    30A/1.2m(2m)/Y terminal, a pai...
  • IT-E30615-OO(Optional)
    60A/1.5m/Round terminal, a pai...
  • IT-E31220-OO (Optional)
    120A/2m/ round terminal one ...
  • IT-E32410(20)-OO(Optional)
    240A/1m(2m)/Round terminal, a ...
  • IT-E33620-OO (Optional)
    360A/2m/ round terminal a pa...
  • IT-E176(Optional)
    GPIB
  • IT-E177(Optional)
    RS232/Analog communication car...
  • AC power cord(Optional)
    AC power cord, 5m
  • IT cabinet(Optional)
    IT cabinet 15U/27U/37U
  • IT-E168/169 (Optional)
    Parallel fiber Suite Single ma...
  • IT-E9003(Optional)
    ITECH Warranty up to 3 years
